HawaiiPunaSenDT87

network: single_reference





















































reference_date.txt

20201015

HawaiiPunaSenDT87.template

process_flag                        = TRUE
frequency                           = 1
user                                = famelung
####################
####################
every_day_flag                      = yes
processor                           = isce
parallel                            = yes
cleanopt                            = 0
hazard_products_flag                = TRUE
ssaraopt.platform                   = SENTINEL-1A,SENTINEL-1B
ssaraopt.relativeOrbit              = 87
ssaraopt.startDate                  = 20140101
#ssaraopt.endDate                    = 20200501
####################
topsStack.boundingBox               = 19.1 19.9 -155.8 -154.5                           # '-1 0.15 -91.6 -90.9'
topsStack.subswath                  = 1 2                                               # '1 2'
topsStack.subswath                  = 1                                                 # '1 2'
topsStack.numConnections            = 2                                                # comment
#topsStack.excludeDates              = 20200301
topsStack.excludeDates              = 20150831,20150608,20150726,20150714,20150807,20150702,20150527,20150912,20150819,20180511,20180523,20151006,20151030
topsStack.azimuthLooks              = 7                                                 # comment
topsStack.rangeLooks                = 19                                                # comment
topsStack.filtStrength              = 0.2                                               # comment
topsStack.unwMethod                 = snaphu                                            # comment
topsStack.coregistration            = auto                                              # [NESD geometry], auto for NESD

########## Miaplpy
minsar.miaplpyDir.addition   = date          #[name / lalo / no ]  auto for no (miaply_$name_startDate_endDate))
miaplpy.multiprocessing.numProcessor              = 40    # auto for 4
miaplpy.load.processor      = isce  #[isce,snap,gamma,roipac], auto for isceTops
miaplpy.load.updateMode     = auto  #[yes / no], auto for yes, skip re-loading if HDF5 files are complete
miaplpy.load.compression    = no  #[gzip / lzf / no], auto for no.
miaplpy.load.autoPath       = yes    # [yes, no] auto for no
mintpy.subset.lalo         = 19.44:19.50,-154.93:-154.840    #[S:N,W:E / no], auto for no
miaplpy.subset.lalo         = 19.44:19.50,-154.93:-154.840    #[S:N,W:E / no], auto for no
#mintpy.reference.lalo       = 19.57,-155.575
miaplpy.load.startDate      = 20180901 #  20200101
miaplpy.load.endDate        = auto
#miaplpy.load.startDate      = 20140701 #  20200101
#miaplpy.load.endDate        = 20180429

miaplpy.inversion.rangeWindow              = 19   # range window size for searching SHPs, auto for 15
miaplpy.inversion.azimuthWindow            = 9   # azimuth window size for searching SHPs, auto for 15
#miaplpy.interferograms.networkType   = delaunay     # [single_reference, sequential, combine, list] default: single_reference

####################
mintpy.troposphericDelay.method     = no                             #[pyaps / height_correlation / base_trop_cor / no], auto for pyaps
mintpy.save.hdfEos5.subset          = yes     #[yes / no], auto for no, put subset range info   in output filename
mintpy.network.startDate            = auto                                              # [20090101 / no], auto for no
mintpy.geocode.laloStep             = 0.00025,0.00025                 #[-0.000555556,0.000555556 / None], auto for None, output resolution in degree
mintpy.load.autoPath                = yes
mintpy.compute.cluster              = local
mintpy.compute.numWorker            = 32
mintpy.solidEarthTides              = no                         #[yes / no], auto for no
mintpy.save.hdfEos5                 = yes                        # [yes / update / no], auto for no, save timeseries to UNAVCO InSAR Archive format
mintpy.save.hdfEos5.update          = no                                                # [yes / no], auto for no, put XXXXXXXX as endDate in output filename
####################
insarmaps_flag                      = True
